YUCHENGTECH Portable Edge Bander Woodworking Edge Banding Machine with Speed Control 2-6m/min Double-sided Gluing – Width 10-60mm-Thickness 0.3-3mm 220V
Product Characteristics
- Supports various types of edge materials, such as PVC, ABS, thin wood chips, etc..
- Applicable to a variety of border shapes, the length and width of the edge is widely used, can be used for straight line edge, can also be used for curve edge.
- The special design of the coating system enhances the stability of the structure, prolongs the use time of the machine, and the coating is more uniform and non-leakage.
- The temperature control device can automatically control the heating temperature to reach the preset temperature, and the heating time is short, only 5 to 7 minutes.
 |  |  |  | |
|---|---|---|---|---|
| Power | 1200 W | 1200 W | 765 W | 765 W |
| Edge banding width | 10-60 mm | 10-60 mm | 10-45 mm | 10-60 mm |
| Edge banding thickness | 0.3-3 mm | 0.3-3 mm | 0.3-3 mm | 0.3-3 mm |
| Edge banding speed | Constant speed 5 m/min | 2-6 m/min | Constant speed 5 m/min | 0.5-5 m/min |
| Heating time | 5-10 min | 5-10 min | 5-10 min | 5-10 min |
| Glue pot capacity | 1000 ml | 1000 ml | 200 g | 200 g |
| Gluing method | double-sided gluing | double-sided gluing | single-sided gluing | double-sided gluing |
| Size | 400*360*370 mm（15.75*14.17*14.57 in） | 400*360*370 mm（15.75*14.17*14.57 in） | 340*310*350 mm （13.39*12.20*13.78 in） | 340*310*350 mm （13.39*12.20*13.78 in） |
| Weight | 14 kg (30.86 lb) | 14 kg (30.86 lb) | 14 kg (30.86 lb) | 14 kg (30.86 lb) |
| Weight: | 8.5 kg |
| Dimensions: | 45 x 44.9 x 40.9 cm; 8.5 Kilograms |
| Part: | NNW-634 |
| Pack Quantity: | 1 |
| Batteries Required: | No |
| Batteries Included: | No |
| Manufacture: | YUCHENGTECH |
| Quantity: | 1 |
| Reference: | NNW-634 |
Muy buena mquina para los cantos de tableros, fcil de manejar.
Risolve il problema dei bordi non precollati senza ingombro e soprattutto senza intaccare troppo il portafoglio
Die Maschine funktioniert soweit. Dem Preis geschuldet ist die Qualitt nicht die beste. Der Tisch ist nicht Plan Zug Maschine ausgerichtet. Ich habe die 7 6mm Schrauben gegen lngere getauscht und Muttern dazwischen geschraubt. So konnte ich den Tisch genau ausrichten. Schade das keine Bedingungsanleitung dabei war. Wenn jemand eine hat knnte er sie hier einstellen. Irgendjemand hat bemngelt das sie gebraucht war. Das ist falsch! Sie werden im Werk getestet. Ich bin erstmal zufrieden.
Bien producto, funciona bien, despus de muchos ajustes hace su trabajo. En resume. Es una mquina la cual tienes q aprender a usar y sobre todo ajustarla y regularla, despus de eso a trabajarla y sacarle provecho.
Hay que aprender a usarla pero una vez que sabes es excelente
La plaqueuse demande de s’entrainer un peu avant l’utilisation. Collage de bonne qualit et rgulier.
Great bit of kit not very often do you buy something that just works.
No es que est usada lo manchada por el pegamento se prueban de fbrica para ver qu suba el pegamento su funcin la cumple bien, pero si quieres mejorarla hasle una buena base y ponle un sistema opresor para tus cortes para que no vallan hacia arriba, una tijera fijada hecha a la medida para cortar el cubrecantos y una base rotatoria para el rollo de cubrecantos y ya tienes la versin de $30k por menos de $10k. Denle buen uso los que empiezan su negocio.
I have been ironing on edges for years because edgers cost so much for my small shop not to mention space. I figured I would give this a try because the price was cheap enough and to my amazement it really works. It requires a rhythm to push the board through at the same speed as it feeds edging but it didn’t take long to get the hang of it. Right out of the box the glue was a little heavy but adjustment was easy. I’m not sure I want to sure it for a portable as it’s a little heavy for that. Also not crazy about the trimmer although its no better or worse than any other hand trimmer. Overall I highly recommend this product for small shops like mine.
It is a good edgebander but the user manual is lacking and you have to watch their video and pause and write down the adjustments on your own and have knowledge on how edge banners work and good luck when you ask customers services about glue for it but the machine itself works good
