DOKIO 300W 18V Portable Foldable Solar Panel Kit (41x21inch
DOKIO 300W 18V Portable Foldable Solar Panel Kit (41x21inch) Folding Flexible Monocrystalline(HIGH Efficiency) Charger with 2 USB Outputs for Phones Work for 12v Battery AGM RV Camping Va
SPECIFICATION
| Maximum Power(Pmax) | 300W±3% |
| Maximum Power Voltage(Vmp) | 18.00V |
| Maximum Power Current (Imp) | 16.67A |
| Open-Circuit Voltage (Voc) | 22.50V |
| Short-Circuit Current (Isc) | 16.92A |
| Maximum System Voltage | DC1000V |
| Foldable Size | 41 x 21 x 1.1 inch |
| Expand Size | 85 x 41 x 0.24 inch |
| Weight | 17 lb |
| ||
|---|---|---|
| Weight: | 7.5 kg |
| Size: | 300W |
| Dimensions: | 100 x 50 x 2.4 cm; 7.5 Kilograms |
| Part: | DOKIO-FFSP-300M |
| Pack Quantity: | 1 |
| Batteries Required: | No |
| Batteries Included: | No |
| Manufacture: | DOKIO |
| Dimensions: | 100 x 50 x 2.4 cm; 7.5 Kilograms |
| Quantity: | 1 |
| Reference: | DOKIO-FFSP-300M |
| Size: | 300W |
Este ao queramos instalar una placa en nuestra T4 California, pero nos enteramos de que los de ITV van a empezar a pedir homologacin as que nos pusimos a buscar algo removible. Esta placa cabe plegada y tumbada tras los asientos y ponerla es sper fcil. Nosotros hemos puesto unas chapitas adesivas de metal tanto en el techo como en la funda de las placas y las dejamos unidas por pequeos imanes de neodimio, pero nada complicado: hablamos de las tpicas chapitas que se les pone al mvil para los soportes del coche; de esta forma la placa se sujeta cuando levantas el techo. Ojo, no vale para ir circulando con ella puesta.
La placa funciona muy bien: nosotros la ponemos un rato por la maana y nos carga todo lo que hemos gastado durante la tarde y la noche. Hacenos mucha ruta y el alternador siempre va cargando, por lo que no puedo asegurar que pueda llegar a ser 100% autnomo con ella, pero dada la velocidad con la que carga un cuarto de batera te dira que s sin problema.
En resumen: por 315 eur que nos cost, la recomiendo sin dudarlo!!
So there’s a lot of reviews about people not getting much out of this panel.
One chap getting 17 watts from two. He is getting that because his solar bank (and ac200P) says he needs three panels to get the voltage required to charge the unit.
However.
If you connect this panel to an allpowers 288WH unit your getting max 56W input. That’s less than a 120W panel. I don’t know exactly why but assume it’s down to the allpowers unit throttling it. I will be testing on the larger 576WH unit, and on the new Anker 757 which is what I bought it for.
Now onto car charging. Totally dead battery this PWM charger even with an initial voltage feed to initiate it won’t charge the battery even though it says it is. I charged on an old fashioned unit for 30 minutes, then swapped back over. The 30A car charger was maxed at 13Amps. Using this panel that’s exactly what I got, so it’s yet again the battery limiting it. 13 amps is in the region of 180 watts including some losses. And we know the battery is limiting it. That’s really good.
You really want an MPPT charger not pwm, but the price is superb. Build quality is good. And they include the standard extra barrel plug that almost all solar power stations use.
The negative reviews are from people not matching the voltage and amperage of this unit to their solar power stations and such.
I am confident we can get around 250W from this unit if it is matched well, with something that doesn’t throttle the charging.
13 amps into a 12V battery laid flat, not angled, on a sunny day is very impressive for a panel you can fold up.
That’s faster than you average and slightly above average mains car chargers.
Super spul , gebruikt voor het opladen van mijn Eco Flow Delta Max
Fr meinen Gebrauch im Wohnmobil ist die Ladeleistung sehr optimal, Lieferung erfolgte zuverlssig und schnell, Verpackung war ausreichend.
Gute Solaranlage,tragbar und auch die Leistung ist prima, habe sie im Womo mit einer 200Ah Batterie verbunden, so kann ich tagelang autark stehen, bin sehr zufriede
Most people buying this will likely be using it to charge a 12v battery perhaps as part of a motor home or van life set up. My use however is a little different and somewhat more truly portable.
I have owned all the major brands smaller 20-30w USB solar panels from the likes of Rav, Bigblue etc… They are good but you run into power limitations when you only have 5v available, and 3.5 amps on a good day.
Enter the dokio panels. I wanted this in order to directly power various USB Buck convertors and USB PD supplies using its 18v nominal output. I am pleased to say I have had great success in doing so.
I havnt tested the units total capability yet however I have been able to pull in excess of 120 Watts via my USB PD testing straight from this panel.
As with all solar panels of this type, you need to take their rated output with a pinch of salt. 300 Watts? Hmmm maybe you might get somewhere in the vicinity of 250 upwards if you are in a desert with ultra high UV, but a more realistic expectation in UK sun would be 200-230w. You have a lot of surface area and that really helps.
I have had the panels out in light to medium rain and they were not damaged so there is probably some resilience there.
The output connector is SAE which is nice and easy to work with.
A basic PWM type 12v solar charger is provided and this appears to work well. However if I was going to charge 12v batteries then I would use an MPPT controller anyway.
Overall this is a good product, it will produce over 200w in bright sun, but take the 300w rating with a pinch of salt.
Pro tip: Use a couple of camping tables as a stand and you can enhance output by angling toward the sun.
Sadly I had to source this product via Ali Express due to delivery issues when I ordered from Amazon, however that’s got no bearing on the product itself.
The 3 main Solar Charger connections are via XT60 connectors keeping it neat, tidy and quick to put together and take apart. 2 x 2A USB sockets work without a battery connected, nice touch.
3pm on a sunny May afternoon in England, panels flat on the ground, and I was getting 11.4A at 14.1V into a battery under load. 160W! Not bad, especially with the bargain basement PWM controller. The controller reduced the Amperage when the load was removed.
The crocodile clips to connect the battery (via XT60 again) are a little flimsy, but okay. SAE to MC4 converter cable worth buying to exploit an existing rig.
All in all top-notch! Not expecting to get anywhere near the 320W potential, but 200W seems in reach. Recommended!
Jetzt soll es noch fr andere Zwecke dienen, z.B. als Untersttzung fr den Wohnwagen.
Generell muss man aber sagen, will man es dauerhaft an windigen Stellen anbringen (wie z.B. einer Segelyacht), sollte man die Last nicht auf die integrierten sen verteilen. Stattdessen ein simples, durch die sen durchgefhrtes, aber selbsttragendes Schotkonstrukt, das keinen Zug auf die sen bringt, hat uns sehr geholfen.
Als nchstes sollte man sich natrlich schwer berlegen, einen MPPT Laderegler zu kaufen, da man sonst nie auch nur ansatzweise in die Nhe von 300W kommen wird.
Das Panel ist im brigen zusammengeklappt unerwartet leicht und immer noch ein wenig flexibel, was es transportabel im Auto / Dachbox macht.
Alles in allem ein Preis/Leistungsmig gutes Produkt, wer mehr erwartet muss auch mehr ausgeben.
I did need to re-terminate one of the terminals on the controller and tighten the other terminals.
Getting to grips with the controller menu took a few moments, but I got there (bottom left button was the key) image on the button is small. It had this graduate engineer at it…Should have tried to follow instructions 1st time and not
double guess
Works as expected. Around 200W on a cloudy day with the Bluetti AC200MAX
