8 Channel CCTV DVR Recorder, DEATTI HD 1080P Lite 5in1
8 Channel CCTV DVR Recorder, DEATTI HD 1080P Lite 5in1 Hybrid DVR for Home Security System with 1TB Hard Drive, Compatible with AHD/CVI/TVI/IP/CVBS(Analog) Cameras
Protecting What Matters Most to You, 24/7
DVR Spec:
- Video compression: H.264
- Encode capacity: 8*1080p lite@25FPS
- Storage: 1×3.5″ SATA hard disk up to 4TB capacity
- Video input/ output: 8CH BNC/ 1CH VGA, 1CH HDMI
- Audio input/ output: 4CH RCA/ 1CH RCA
- Interface: 1* RJ45 10/100M for network, 2* USB 2.0
- Record Mode: Schedule/Manual/Stop
- Backup Mode: Network, U disk, USB burner, SATA burner
- Network: PPPoE, NTP, EMAIL, DDNS, FTP, etc.
- Power: 12V / 2A
 |  |  |  |  |  | |
|---|---|---|---|---|---|---|
| DVR/NVR Resolution | 1920 x 1080 (1080N) | 1920 x 1080 (1080N) | 1920 x 1080 (1080N) | 1920 x 1080 (Full HD) | / | / |
| Camera Resolution | / | / | / | 1920 x 1080 (Full HD) | 1920 x 1080 (Full HD) | 1920 x 1080 (Full HD) |
| Video Input/Output | TVI/AHD/CVI/CVBS/IP | TVI/AHD/CVI/CVBS/IP | TVI/AHD/CVI/CVBS/IP | Auto Pair | AHD | AHD |
| DVR | 8 Channel | 4 Channel | 16 Channel | 4 Channel | / | / |
| P2P | PC / Phone(iOS and Android) | PC / Phone(iOS and Android) | PC / Phone(iOS and Android) | PC / Phone(iOS and Android) | / | / |
| Video compression standard | H.264 | H.264 | H.264 | H.264 | / | / |
| IR LEDS, Night Vision | / | / | / | 36pcs, 98ft/30m | 24pcs, 65ft/20m | 36pcs, 98ft/30m |
| Lens, View Angle | / | / | / | 3.6mm, 80 Degree View Angle | 3.6mm, 80 Degree View Angle | 3.6mm, 80 Degree View Angle |
| Waterproof Level | / | / | / | IP67 | IP67 | IP66 |
| Weight: | 1.75 kg |
| Size: | DVR |
| Dimensions: | 24.99 x 21.01 x 4.5 cm; 1.75 Kilograms |
| Model: | DE-8Dc2M1TB(2TB HDD) |
| Part: | 8CH 1080N DVR(2TB HDD) |
| Colour: | 8ch Dvr W/1tb Hdd |
| Pack Quantity: | 1 |
| Batteries Required: | No |
| Batteries Included: | No |
| Manufacture: | DEATTI |
| Dimensions: | 24.99 x 21.01 x 4.5 cm; 1.75 Kilograms |
| Quantity: | 1 |
| Size: | DVR |
Had Annke cttv before worked ok but this one is far better picture quality and options are great much easier to use than others
I’ve inst.installed 5 of these dvr s and never had a problem
I like the straight forward plugin and go but, You need to read instructions to know how to watch playback and playback is a little complex.
I bought this item in august 2019 and today I have come home yet again to the screen saying format has finished I click ok and next day it’s back on the screen any ideas ???? Other than this error very good system
One thing I think customers should be aware of,is that this will only work with routers working of 2.4ghz. Now,most routers are switchable between 5ghz and 2.4ghz,but you will need to go into your router settings to switch 5ghz off…and leave 2.4ghz on. If your not sure how to safely change your router settings,then Google is the safest bet…Once you’ve connected via 2.4ghz,you can safely go back into your router settings and switch 5ghz back on again..Overall,great for the price,Xmeye is easy to install,so would def recommend if your confident enough about diving deep into your router settings….
Bought this unit and after a few weeks operation had a little problem. Following updates, changes to settings and new software, everything seemed to work. Then total failure, wouldn’t record. The unit was changed with no hassle. Efficient and painless service. Thanks to Deatti for all their help.
This is a great value product! I bought this as a replacement for my previous box and it work a treat. Very good quality and great value for money. The android app works fine on mobile phone. The support email gives you the latest program to use on PC. Very helpful.
Having been using this product for 18 months without an issue, unfortunately something happened and it stopped working. I contracted customer service and they sent out a new power supply that resolved the problem. It’s a welcome surprise when you get such rapid response for something you bought nearly two years ago. Would highly recommend this DVR manufacturer.
I liked t Design easy to use Picture quality brilliant and most of all very easy to install
The after sales service is second to none like give it a 5 star rating
Regards
Angela
Great pics. Struggled to get colour at first. Turns out, needed to manually set up cameras. Great after that…
Nothing to dislike about this item, with deatti cameras it is unbeatable as far as I am concerned, and great support from deatti
The first box we received was faulty but the customer service was excellent and they sent out a new box which works perfectly.
Decent quality, easy to set up, works good with the android app. Been working fine for a while now. Set up to record activity 24/7
Great value for money. Old unit died a death so this was a simple swap out and I was up and running in literally minutes.
Its brilliant and easy to set up and app is good too.
Just get it if you’re thinking about it.
I had another 4 channel unit and this works better and is easier to setup.
I purchased this DVR to replace a previous lesser DVR as part of an upgrading of an existing CCTV security system, but am absolutely amazed at the extent to which this DVR has brought my existing cameras to life, with clearer daytime coverage, and with low-light clear colour or infrared at night where there was previously very little coverage.
The DVR is supplied with a User Manual, in which the seller also supplied a PDF version after purchase. The User Manual gives full details of all the on-screen menus and options available but unfortunately does not provide details of the way in which these options are to be put to best use, thereby leaving the user to discover for themselves, albeit that adverse reviews would suggest that this can sometimes lead to unfortunate outcome.
This DVR is however suitable for first-time DVR users in that when a CCTV camera is plugged in the DVR automatically sets up the camera into use, in which the user can then operate the DVR on its default settings without the necessity to customise, or for selective customisation at a later date, with default options available on all features as a safeguard.
In that I have quite specific security requirements, I have for the past two weeks been putting this DVR through all of its features, albeit for use as a standalone DVR therefore not linked for Smartphone use.
All in all therefore this CCTV DVR provides excellent quality in all that is needed and is therefore to be thoroughly recommended and well worth trying.
For starters therefore:
The DVR uses a CR2032 button battery for time/date stamping which is preinstalled but will need to be replaced occasionally.
The DVR camera connections require BNC cable with metal locking connectors — BNC plastic connectors will need BNC locking adaptors — the cable with locking connectors proving to be the better option.
The AV and audio out connectors also require BNC locking connectors — these can be used to output via a scaling converter as in BNC to SCART or other such converter for output to older televisions or in making use of other types of unused TV connections — in which the picture quality is as good as that via HDMI. An HDMI scaling converter could be used for the same purpose.
As with all DVR’s, in connecting the CCTV cameras the wires should lie alongside each other, not tangled, and not crossing over each other. The mouse cable and DVR power cable should not be near or touching the camera cables.
To date I have not encountered any restrictions in the use of the camera connections. It is always better to let the DVR install the cameras and set itself up, and then only adjust what you need to adjust.
A case therefore of connect the cameras, connect the mouse, plug the DVR in, open the Wizard , create your login password , set the time zone, select the way you want the date to display, close the wizard, and then enjoy.
Right click to display the mini menu, at the bottom select from the camera display options — or left double-click on a camera image to view one camera — the mouse scroll wheel will also scroll from one single on screen camera to the next.
With one camera on screen, holding the mouse left button down, pull out a small rectangle in the shape of your screen, left-click inside the rectangle to zoom without a zoom camera, left double-click to return to normal display.
To adjust the colour or clarity on a camera, or improve older cameras, select the camera, right-click for the mini menu, select colour setting, adjust the contrast and saturation, and during night-time darkness.
To set up recording – from the mini menu select main menu and then select Record.
This allows the user to set all the cameras to record all the time, or individual cameras to record at scheduled times — I set All to record at all times but only by way of motion detection, therefore unchecking the Regular box.
To set up motion detection – from the mini menu select main menu and then select Alarm.
If All is selected to set all the channels at once, when one detects motion all the channels will record – therefore for each individual channel for motion detection separately select the channel number and check the enable box to turn the motion detection on.
The pre and post record options add a little recording time either side of the actual, I have the Record pre-record set at 30secs and the motion detection post-record set at 120secs.
The scheduled recordings perform well and the motion detection is well-responsive on Middle sensitivity albeit adjustable.
Main Menu > Record > Playback allows the playback of all recorded material channel by channel by selection, or by continuous run-through, with pause, stop, fast or slow forward and back, or frame by frame, in fairly standard format therefore, albeit not quite as featured as on my previous DVR.
Main Menu > Record > Backup allows the backing up of recorded material onto a flash drive or other external storage facility.
Main Menu > Record > Backup > Detect will detect the plugged in storage device if not displayed.
Main Menu > Record > Backup > Backup
Clear any existing listed files from previous back-ups by clicking the Remove button.
Select the channel – right-click on each date and time number to set the period — click the Add button — do the same again to add other recorded files to the list – select the back-up format and click Start.
Whilst this will readily backup files in MP4 or H264/5 each requiring specific players, when it came to backing up in the more widely used AVI format, the DVR proved to be temperamental until I did battle to get the better of it. Once achieved the quality of the backup is good.
These the essentials – other features being a matter of choice.
Excellant recorder with 8 channels. Just what we required and space left for more cameras if we want.
Have had this DVR since May 2020 with no problems at all until it suddenly stopped.
Contacted Deatti and followed their check list.
Lisa at Deatti then arranged to send a replacement direct from China.
I have found that Deatti provides great value for this DVR and can highly recommend.
The after sales service could not be faulted in any way. Very pleasant lady.
Use this product for site security. It gives easy remote access and recording. The motion detection allows for longer recording cycles on the available hard disk space. I am very happy with it after one week.
Appears to be a good product. Mobile app set up after a bit of a struggling finding model number within the menu, but works great now. Good after sales service with minor problem. Would recommend.
It’s a powerful DVR with lots of functions and naturally appeared a bit complicated at first.
Motion detection and play playback worked very well.
The XMEye app was quick and easy to setup and use. During the DVR’s setup, it gives QR codes on the monitor screen for the XMEYe app download and the DVR’s serial number needed to register the app on my phone.
In addition to the VGA and HDMI outputs, there is a conventional video output. This was welcomed as I could relay the monitor screen view to a TV 50 feet away from the DVR down a single piece of coax.
I could connect my PC to the DVR using its IP address via Internet Explorer. This needed a plugin called Net Surveillance Web (available from a link on the login screen). Chrome and Edge browsers did not work with this DVR.
Viewing live and recorded videos using the XMEye and Net Surveillance Web interfaces was easy and effective. The mouse driven interface on the DVR box itself had the advantage of being able to review recordings from several cameras simultaneously – a very powerful feature.
I had a problem with the power adaptor supplied but customer service was very responsive and it was quickly resolved. Used WhatsApp to discuss the issue in real time. If it wasn’t for that snag and the manual being a bit unclear in places, I would have given it 5 stars overall.
Great product, installed very easy and replaced a much more expensive product. Very pleased with the DVR and with the service I received
Our previous cctv developed playback problems and hence replacement required. Not an easy task. The Deatti system ticked the boxes and received good reviews so decision made.
Ordered on a Friday and up and running on the Saturday. Easy setup using QR code to enable installation of XMEye.
Cannot find any fault with purchase. Recommend this for good value for money.
Brought this to replace my existing dvr for my security system. Found it very easy to set it up and found the
Instructions very easy to follow. Would recommend this dvr.
Does the job, bought to replace a DVR that had come to the end of its life. No issues. Would recommend.
I connected everything including the network cable to my router then switched on. If you follow the setup wizard it was easy and connected to my router automatically. I downloaded the app and within minutes I could see all my cameras on my iPad and iPhone.
I use the big old Samsung HD-SDI DVR SRD-480D, with the big thick coaxial cable, with its crystal clear image just like watching a high definition TV with its full-size circuit board and a built-in cooling fan so I have been spoilt. ( I purchased it off of Amazon a long time ago ). it is big and old so I wanted a new one thinking newer would be better.
The “Deatti 5-in-1 DVR” is small the circuit board is smaller than the hard drive. I have lots of CCTV cameras it recognised almost all of them apart from my Samsung SRD-480D cameras. The Deatti DVR is virtually plug and play easy to set up.
An example of the image you would see I took a photograph of the tiny remote control compared to my one and slightly adjusted focus to give you an idea of the image it sees. I have loads of CCTV cameras from different camera makers and all of them had a delay if you waved your hand back and forwards.
For the money it is good enough quality it is typical of shop CCTV images. My 11 year old Samsung HD-SDI DVR SRD-480D is still king. I will keep this Deatti DVR, for a backup. I work and live in a nasty area.
Bought this DVR as a replacement of another brand I got few years ago. This DVR works fine. Instructions was very clear – I had a slight issue with the set up process, contacted customer service and everything was resolved very quickly, so thank you to L for your help. Definitely would recommend this product – great price, DVR works perfectly and excellent customer service!
Bought only the DVR as a replacement for our school’s old system (which was fried by a power surge). Plugged it in, attached the existing cameras, and it was up and running in less than 10 minutes. The setup wizard made it easy. Opted to get more details on the email alert setup, which they supplied promptly. The documentation was clear. I would rate this product as an excellent value given its cost.
We already had cameras from a previous system so we were just replacing the DVR. It was easy to set up and the instructions were clear. Managed to get the PC viewer working as well as the phone app.
I bought this product as a replacement for a DVR that had died. It was very simple to set up, the only thing that I found I had to do was set up the remote viewing app manually as the QR reader did not open the app, this was a simple task and minutes after opening the box, everything was working! Many thanks for a reasonably priced DVR with built in memory.
Bought this one to replace my one which broke and have to say it ticks the box.
Easy to set up and navigate around, so ues i would recommend this item.
Easy to use DVR, my first order had a faulty hdd but quickly got a new dvr and now everything works perfec
The item was dispatched quickly and arrived quickly as well. Was easy to set up with an easy user interface. You also get great customer service and support with this brand. Would highly recommend for shop CCTV or even just for home use.
I have not set the Motion detection area yet but at default settings it runs constantly because of a bush moving in the wind.
To view the cameras on a PC a download is available. Returned my request the next day.
I was apprehensive about this dvr as it is so cheep but was blown away of the quality and easy set-up.
This dvr allows you to view the footage from a phone with NO MONTHLY FEES !!!
All you need is the app on your phone and an ethernet cable to plug between the dvr and your internet router, the set up was all explained in the manual that comes with the product.
Very happy 🙂
The system does exactly as per the spec and easy to setup.
However, if you are unsure how to setup the remote access or need help setting up your device. The after service team provides an excellent support and service.
My device is working and doing what it should do.
Got 7 cameras working with a spare spot in case I want to expand easy to set up and use
To replace a failed recorder. This one is faster and clearer than the one it replaced. Easy setup. Very pleased.
Used this to replace a Swann DVR that had failed more than happy with it for the price, I would definitely recommend
Used this to replace an old system, worked straight out of the box with no fuss, app works fine all very easy to set up
Have fitted 3 of these systems, all worked well easy to install comes with cables easy to connect as well. The app to see cameras on your phone works well and is easy to connect, this is a good quality low price product would recommend highly
What I like most about this DVR is the ability to a access my cameras from outside my home. I have older cameras and it recognised them straight away. The provided software is easy to use, but above all I know if I ever have a problem either hardware or software based help is always promptly given when asked for. I would definitely have no problem in recommending this product to anyone.
For the price does what it says on the tin.
This dvr has now been set up for 2 months works very well the app means you can check the cameras and play back anywhere in the world as long as you have internet
The customer is second to none.I would highly recommend the product and the company
It really is plug and play as long as you use the QR code and you write down your user name and password ready to refer to later.
I have established 20 camera’s on two systems 3 phone receiver’s and 4 TV as monitor’s and it also play upto 1months historical recording.
I am now able to monitor 2 separate houses 50 miles apart or even when I am on the move with and without WIFI.
Without WIFI you use Data on your sim card.
Luck
Bought this to replace my current DVR (connected to analog cameras). It was extremely easy to set up and the picture quality is great. So far I have not had any problems with it. I would highly recommend this product.
Took some time to configure, the instructions were Ok but sometimes chinese instructions don’t seem to flow that well although these were better then others I have tried to understand. I have managed to set up to view cameras on a stand alone monitor, Iphone and PC and all are working well. Overall great value for the money. Arrived quickly and very securely packaged. Only had the DVR for a few days so unable to judge reliability.
Bought as a replacement to old system by another manufacturer, using old connections made it a straight swap. Very easy to set up and took minutes to connect to my phone for remote viewing. Great support from the seller with offers of help if needed
Good product. Poor English in manual. Download link for Active X component for PC browser did not work. Got one from 3rd party site and all OK.
Great value for money product with excellent customer service received. The Customer Service Team answered all my pre-purchase questions as needed to check if the DVR was compatible with my camera set up. XMEye app and DVR set up was simple with full instructions provided. DVR slightly noisier than previous DVR, however the noise isn’t distracting. Well worth purchasing.
So easy to set up and better to check all recordings at once on TV screen
Defo recommend I had a few issues and emailed them it got sorted well
The on line support from Seller was 1st class. Providing information on Products as well as support made the purchase even better.
I would highly recommend the Seller for Product Quality and 1st class communications.
However overall a solid unit if you are just looking to replace an older model.
best dvr on the market. price is really good value ..it’s easy to set up and has all the best up to date features like live viewing on a tablet or pc ..you can use different cameras .4 audio inputs and out puts ..email motion detection etc etc ..
Update: After writing the above review, Deatti contacted me to apologise for the problems with this DVR. The outcome being, a partial refund of the purchase price. I have to say that Deatti’s customer service is second to none. I was very pleasantly surprised by this company and even though I was a bit disappointed after the original purchase, I would definitely buy from this company in the future.
