Waveshare ESP32-S3 4inch Capacitive Touch Display
Waveshare ESP32-S3 4inch Capacitive Touch Display Development Board, 480×480, 5-Point Touch, 32-Bit LX7 Dual-Core Processor, Up To 240MHz Frequency, Supports WiFi, With Onboard Antenna
 ESP32-S3-Touch-LCD-4 |  ESP32-S3-Touch-LCD-4.3 |  ESP32-S3-Touch-LCD-4.3B |  ESP32S3-TouchLCD-4.3B-BOX |  ESP32-S3-Touch-LCD-5 | ESP32-S3-Touch-LCD-5B |  ESP32-S3-Touch-LCD-7 | |
|---|---|---|---|---|---|---|---|
| Customer Reviews | 3.8 out of 5 stars7 | 3.5 out of 5 stars38 | 4.7 out of 5 stars5 | — | — | 5.0 out of 5 stars2 | 4.1 out of 5 stars26 |
| Price | £40.99 | £38.99 | £45.99 | £51.99 | £44.99 | £48.99 | £46.99 |
| Flash/PSRAM | 16MB Flash + 8MB PSRAM | 8MB Flash + 8MB PSRAM | 16MB Flash + 8MB PSRAM | 16MB Flash + 8MB PSRAM | 16MB Flash + 8MB PSRAM | 16MB Flash + 8MB PSRAM | 8MB Flash + 8MB PSRAM |
| Power Supply | TypeC 5V + DC 7-36V | TypeC 5V | TypeC 5V + DC 7-36V | TypeC 5V + DC 7-36V | TypeC 5V + DC 7-36V | TypeC 5V + DC 7-36V | TypeC 5V |
| Resolution | 480×480 | 800×480 | 800×480 | 800×480 | 800×480 | 1024×600 | 800×480 |
| Display Interface | RGB | RGB | RGB | RGB | RGB | RGB | RGB |
| Display Panel | IPS | IPS | IPS | IPS | IPS | IPS | IPS |
| Viewing Angle | 160° | 160° | 160° | 160° | 160° | 178° | 170° |
| Touch Type | capacitive | capacitive | capacitive | capacitive | capacitive | capacitive | capacitive |
| Touch Panel | Toughened Glass | Toughened Glass | Toughened Glass | Toughened Glass | Toughened Glass | Toughened Glass | Toughened Glass |
| Dimensions (L×W) | 84.2×84.2mm | 106.1×67.8mm | 112.4×75.1mm | 116.3×79mm | 127.7×87.45mm | 127.7×87.45mm | 192.96×110.76mm |
| Operating Temperature | 0℃ ~ 65℃ | 0℃ ~ 65℃ | 0℃ ~ 65℃ | 0℃ ~ 65℃ | 0℃ ~ 65℃ | 0℃ ~ 65℃ | 0℃ ~ 65℃ |
| Weight: | 122 g |
| Dimensions: | 14.48 x 10.41 x 2.29 cm; 122.47 g |
| Brand: | Waveshare |
| Model: | ESP32-S3-Touch-LCD-4 |
| Batteries Included: | No |
| Manufacture: | Waveshare |
| Dimensions: | 14.48 x 10.41 x 2.29 cm; 122.47 g |
