Portable Monitor ELECROW 10.1 Inch CCTV Monitor 1920×1080 Resolution IPS Screen Small Monitor with HDMI and VGA Input Compatible with Raspberry Pi CCTV Computer Game Console PC Windows 7/8/10, VESA
ELECROW 10.1-inch 1920X1080p HDMI VGA Portable Monitor
With Full HD 1080p support, the HDMI monitor delivers spectacular image quality.
Applications
1. The Raspberry Pi screen could compatible with raspberry pi, such as Raspberry pi 4, Raspberry Pi 3, etc.
2. This portable monitor can be used as a CCTV monitor too.
3. ELECROW’s HDMI monitor can be used as a display of PCs and Industrial equipment.
4. Use this small monitor for game consoles.
5. Use as a monitor for medical equipment.
6. This portable monitor can also be compatible with VGA output devices.
Notice:
When working with Raspberry Pi 4, please comment out by adding # in the front of “dtoverlay = vc4-fkms-V3D” or delete this line directly in the config.txt file.
VESA Wall Mount Pattern
Using the VESA wall mount pattern, easily mount your CCTV monitor on the wall in a manner that is both aesthetically pleasing and conveniently practical. You will be able to save ample space and view the screen in a position that affords the greatest visibility possible. Please use 4mm-6mm M3 screws.
IPS Screen with a Wide View Angle of 170 Degrees
IPS provides advanced in-plane switching technology for premium color performance at any viewing angle.
Notice:
The circuit design of the display is not suitable for being powered by the power supply interface on the car. The car may output exceed the 12V rated voltage of the display, which will cause damage to the monitor.
Better for Your Eyes
With Flicker-less technology say good-bye to annoying screen flickering, and with a blue light filter, your eyes will escape injury from blue light.
Package Includes:
10.1 inch HD IPS Screen Portable Monitor x 1
12V/2A Power adapter x 1
HDMI to HDMI cable x 1
Metal Rack x 1
Specifications
| Signals Input: | HDMI/VGA |
| Screen Size: | 10.1 inches |
| Aspect Ratio: | 16: 9 (width: height) |
| Panel Brightness: | 350cd / m² |
| Contrast: | 800: 1 (Min) (transmission) |
| Resolution: | 1920X1080, up to 1080p |
| Viewing Angle: | 170 degrees wide viewing angle |
| Appearance Size: | 255mm x 164mm x 28mm |
| Display Mode: | Constant black display, transmission type |
| Display Color: | 262K/16.7M (6-bit/6-bit+Hi-FRC) |
| Response Time: | 13/12 (TYP) (Tr/Td)（ms） |
 |  |  |  |  |  | |
|---|---|---|---|---|---|---|
| Size | 10.1 inch | 10.1 inch | 8 inch | 8 inch | 7 inch | 15.6 inch |
| Resolution | 1920×1080 | 1920×1080 | 1280×800 | 1280×800 | 1280×800 | 1920×1080 |
| Touch | No | Capacitive Touch | No | Capacitive Touch | No | No |
| Interface | HDMI & VGA | HDMI & VGA | HDMI | HDMI | HDMI | HDMI & Type C |
| Weight: | 1.16 kg |
| Dimensions: | 25.5 x 16.4 x 2.8 cm; 1.16 Kilograms |
| Brand: | ELECROW |
| Batteries Included: | No |
| Manufacture: | ELECROW |
| Reference: | 10 inch blue |
This is basically a proper monitor in every way except size, the image quality is great and it works perfectly.
The only minor gripe is there is a plastic protective layer over the screen when it arrives, there is a tab that you need to pull to remove it but they are just glued together. As such, when you pull the tab, the tab comes away and leaves the plastic layer in place. Which means you’re going to be there for 10 minutes trying to get this layer off with a pair of tweezers and trying not to scratch the plastic underneath.
Pros:
– Sharp 1080p picture
– Light weight
– Adjustable display settings
Cons:
– Audio. The speakers audio balance is off and the headphone Jack has slight white noise when no audio is playing.
– Casing. The plastic feels cheap at first, but I don’t hold the display.
– Stand. Its ok if you dont have anything else.
Overall, for being a small portable display, its a 10/10 if you do not require sound to be played from this device.
I have a bunch of servers on a switch that I use one monitor for. The old monitor was quite big and clunky given the screen real estate. Ordered this, as I needed the VGA input. Reasonable price, good size, and easy to view/read HD screen. Held off any review as some comments mentioned short lifespan but a few months on all is well. Monitor came with a rack style stand. There was an offer for a free traditional stand in the box. The free stand arrived within 48 hours of the requested details being provided.
Very good all round hdmi port is on the side which means you have to get a 90degree cable to hide it.
One of my lockdown projects was to hook up the RTSP feeds from my Ubiquiti Cameras to a Pi and small monitor having found out how to do it all. This monitor does the trick. Great quality picture from my cams. Reference is made to Pi4 in the description and the need to comment out a line in a conf file. I didn’t find that necessary. VESA mounts means I can fix the Pi to the rear of the unit once I have got the appropriate case and shorter cables.
The stand is a bit naff, but would be hard pressed to deduct a star for that. It does what is supposed to do and keeps the monitor on my desk. By definition, it stays switched on whenever I’m in the office at the back of the house so i can keep an eye on what is going on. Only time will tell if the monitor lasts OK. Shame that Ring doesn’t allow a live feed for their doorbells outside of their ecosystem as then I could add that as well!
This is a good screen with excellent picture quality. I can’t comment on the sound as I’m not using it.
One thing to note is that I am running it with a Raspberry Pi and when the screen is on there is quite a large amount of RF interference. It doesn’t trouble me for my application, but watch out if putting it near Bluetooth devices.
using this with both a raspberry pi and lattepanda SBC via a HDMI switch – very compact but gives full screen for all uses
Excellent screen. Works great on all my RPi’s from pi zero to pi 4. Often use it as a second screen on Pi 4. Only wish it had a USB power connection. So I ordered power bank with a jack plug to make it portable.
Amazing monitor, and the screen is antiglare. Using on my MacBook as second monitor.
The monitor works very well as a monitor on my old Pi B+. I cannot try the touch screen with this model of Pi.
Very nice display. Stand is flimsy but it doues the job
It works straight away with Raspberry pi 3+ and windows did not try mac but I don’t see any reason not to. If it was Touch screen that would be perfect.
