Steinel IS 130-2 Motion Detector, 130° Motion Sensor, 12 m Reach, IP 54, Maximum 600W, 230 V Mains Powered
Intelligent Sensor Technology by Steinel
Live comfortably and save energy at the same time. One of our classics, now with optimised design and technology. The infrared motion sensor IS 130-2 is the perfect solution for the targeted surveillance of surfaces around the house, thanks to its excellent quality of detection in an area of up to 150 m².
Our Company
Steinel develops and manufactures sensor lights in its own factories in Europe. Made in Europe is our winning formula – and has been for over 50 years. Our products are renowned around the world for their easy handling and their longevity. Convince yourself!
Motion Sensor IS 130-2
Targeted Surveillance Around the House
Thanks to the adjustable lens, which turns through 50° and tilts through 90°, the sensor can be adapted perfectly to the specific conditions of its environment. Additionally, the detection zone can be reduced with the included lens covers. The time setting and the twilight threshold are easily adjustable via rotary controls on the bottom of the sensor. Thanks to the large and uncluttered connection compartment, the infrared motion sensor is easily wired and installed on a wall.
Twilight Setting (2- 2000 lx)
When the light level drops below the set brightness level the sensor is activated.
Time Setting (8 s – 35 min)
Adjustable time period in which the light stays on after a movement is detected.
Pivot Range
50° horizontal und 90° vertical indicates the sensor’s pivot range.
IP54 Protected
Protection against damaging dust ingress as well as splashwater from all directions.
Intelligent Infrared Technology
| | | | |
|---|---|---|---|
Adjustable Motion SensorThe zone of detection can be adapted to the specific local conditions by adjusting the lens, which swivells through 50° and tilts through 90°. Additionally, the angle of detection can be limited with the included lens covers. | Heat RadiationDue to their body heat humans emit infrared radiation. Infrared sensor technology uses this radiation to detect movement and to react accordingly. | The Pyro SensorThis electric module reacts as soon as the infrared thermal radiation within the detection zone changes. This causes a voltage jump which is then converted into an electronic impulse, which switches the light on or off. | ReachThe reach of infrared sensors depends on the direction of movement. With tangential movements (parallel to the sensor) the reach is about 12 m on average, which is shortened when moving directly towards the sensor (radial movement). To attain the maximum reach the optimal mounting height of 2m should be given. |
 |  |  |  |  |  | |
|---|---|---|---|---|---|---|
| Passive infrared sensor | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ |
| Point of use | In – and outdoor | In – and outdoor | In – and outdoor | In – and outdoor | In – and outdoor | In – and outdoor |
| Mounting | Wall, corner | Wall | Wall | Wall, ceiling | Wall, corner | Ceiling |
| Angle of detection | 180° with 90° angle of aperture | 140° | 130° | 120° | 240° with 180° angle of aperture | 360° with 180° angle of aperture |
| Swivelling range | – | 180° | 50° | 60° | 160° | Fine adjustment |
| Tilting range | – | 90° | 90° | 160° | – | – |
| Reach | max. 12 m or 5 m | max. 14 m | max. 12 m | max. 10 m | max. 12 m | max. 12 m |
| Twilight threshold | 2 – 2.000 lx | 2 – 2.000 lx | 2 – 2.000 lx | 2 – 2.000 lx | 2 – 2.000 lx | 2 – 1000 lx |
| Time setting | 10 sec. – 15 min. | 8 sec. – 35 min. | 8 sec. – 35 min. | 8 sec. – 35 min. | 10 sec. – 15 min. | 10 sec. – 15 min. |
| Max. output | 1000 W | 1000 W | 600 W | 500 W | 1000 W | 2000 W |
| Weight: | 160 g |
| Dimensions: | 8.4 x 7.8 x 13 cm; 160 Grams |
| Brand: | STEiNEL |
| Model: | 035761 |
| Part: | 035761 |
| Colour: | Charcoal |
| Pack Quantity: | 1 |
| Batteries Required: | No |
| Batteries Included: | No |
| Manufacture: | Steinel |
| Colour: | Charcoal |
| Quantity: | 1 |
Funktioniert sehr gut, die Montage ist einfach und lsst sich gut einstellen.
a differenza di note e grandi marche, non ha mai dato problemi
Installation und Einstellungen hatte ich mir schwieriger vorgestellt, mit Geduld und Spucke lief es dann.
Ein tolles stylisches Produkt, was immer funktioniert.
Der Bewegungsmelder lsst sich super installieren und einstellen.
Perfekt fr Haus und Garte
Ich habe ja bereits in meinen anderen Rezensionen darauf hingewiesen, dass ich begeistert bin von meinen Steinel Auenleuchten. Diesen Bewegungsmelder habe ich davor geschaltet. Sehr zuverlssig und genau. Die Lieferung erfolgte schnell. Ich kann einen Kauf nur empfehlen!
je l’ai utilis pour remplacer un vieux dtecteur et il fait parfaitement le travail !
Correspond parfaitement a la description. Installation et reglage facile et rapide.
Seul bmol, manque un reglage pour la distance de dtection, mais se corrige en jouant sur l’inclinaison de la lentille.
Je recommande
Installation facile, le produit est bien pens pour son ouverture, sa fixation et la connection des cbles.
Le rglage est classique avec le seuil de luminosit et la dure. Il faut y aller ttons comme d’habitude pour ce genre de produits.
Jolie look, la couleur anthracite est classique et se coordonne avec tout ce qui est gris RAL 7016 par exemple.
Funktioniert sehr gut, Installation erfolgte durch einen Fachmann. Man kann sehr gut den Winkel einstellen und die lnge der leuchtdauer.
Die Qualitt ist sehr gut. Montage kinderleicht. Zwei Anmerkungen allerdings: 1. der BWM reagiert nur in einem Umkreis von 4-5 m. Wie die meisten Hersteller auf 12 m kommen, kann ich nicht nachvollziehen. Ich habe im Prinzip alle mglichen Winkel ausprobiert. Das zweite ist die Kabeleinfhrung. Die Einfhrung eines 5×1,5 NYM Kabels ist auf Anhieb nicht mglich. Ich habe nur die einzelnen Adern, die ich gebraucht habe, reingezogen. Mit dem Ergebnis bin ich aber zufriede
