G Oil Transfer Pump Air Operated Pneumatic 12LPM PRO Heavy

G Oil Transfer Pump Air Operated Pneumatic 12LPM PRO Heavy Duty Double Action 3: 1 Fast High Flow Rate for SAE 30 Oils/Liquids Oil pump (NOT for Gasoline or Diesel)


GGGG

Professional Specifications

Suitable for use of oil to SAE130 (Refer to to the image)

Pressure ratio: 3:1.

Air inlet pressure: 5-8bar/ 70-115psi.

Max fluid pressure: 24bar/350psi.

Air motor effective diameter: 63mm.

Air consumption (per minute): 8bar/110L.

Max. free flow rate (per minute): 12L.

Quality Performance

This pump is also suitable for typical fluids including: motor oil, synthetic oil, hydraulic fluid, gear oil, waste/anti-freeze fluids & automatic transmission fluid.

High quality pipe milling, delivering a secure fit & strong pipe that won’t break.

Resilient oil filter, to catch unwanted debris.

Differential air motor ensures smooth pumping.

Versatile Mounting

The 3:1 ratio Pump comes with a 270mm / 10.6″ Extension Tube, ready for wall mounting specifications.

Wall Mount/Cart/Barrel Application: ready to mount by wall or cart, to suit the best advantage you need.

This unit does not come with extension tubes, cart or hose.

Suction tube diamater: 42mm.

Suction tube length: 270mm.

Air inlet connection: 1/4″ quick plug, 1/4″ NPT Female.

Oil outlet connection: 1/2″ M.

Reliable Design

The 3:1 is perfect for fluid oil transfer in high volume & longer distance applications, such as vehicle shops / service fleet facility applications.

Smart design utilizing non corrosive materials, with few moving parts in the air motor assembly means less downtime and low repair cost, overall less pump wear & tear.

Air operated for integration into dispensing system, with an air porting design, providing efficient use of compressed air supply for continuous pump operation without icing.

Light weight, high efficient, & double acting.

GGGGGG


Weight: 4.26 kg
Dimensions: 62.5 x 13.5 x 13.5 cm; 4.26 Kilograms
Batteries Required: No
Batteries Included: No
Manufacture: Intradin
Dimensions: 62.5 x 13.5 x 13.5 cm; 4.26 Kilograms
